Del Sol Railer Plus i/O Throttle ST
$1,799.99 - $2,099.99
Details
- Voluptuous 26"+ tires shamelessly flaunt a supple ride with a soft bounce
- E-bike specific hydraulic brakes with 2x the pad thickness and an engine cut-off
- Look-at-me styling including throwback, big-BMX bars and a roaring rat rod silhouette
- Throttle reduces effort to get up to speed
- Monstrous 750W hub motor and throttle accelerate to speed quickly
- High-capacity 840Wh / 17.5Ah fully internal battery provides real range for the big motor
- Double-wall, eyeleted rims and reinforced fork designed to handle big power and torque
- Class 2 e-bike: throttle only or pedal assist up to 20mph
Specs
| Frame | Railer plus | rust-proof 6061 heat-treated aluminum | TIG-welded construction | fully internal battery | 120mm threaded BSA bottom bracket shell | I.S. Disc brake mount | 175mm hub-drive spacing | bottle opener | cartridge kickstand mount |
|---|---|
| Fork | Railer | 4130 chromoly | I.S. Disc brake | 203mm rotor clearance |
| Rims | Railer Plus | Alloy | Width (internal): 50.4mm | Double-wall construction | Eyelets | 36h |
| Tires | Cruiser Plus | 26 x 3.0" |
| Bottom Bracket | 120mm threaded BSA shell | JIS square taper | Sealed cartridge |
| Crankset | 3-piece | Forged alloy | 42T chainring with dual-guide design |
| Shifters | Shimano Revo | 8-speed |
| Rear Derailleur | Shimano Tourney TX800 | 8-speed |
| Cassette/Freewheel | Shimano Tourney CS-HG200-8 cassette | 14-32T |
| Chain | KMC Z8.3 | 8-speed |
| Brakes | Tektro HD-E395 | E-bike specific | 5mm extra-thick brake pads | Heat-reducing external metallic banjo fitting | 203mm oversized front / 180mm oversized rear with 2.3mm extra-thick, I.S. 6-bolt rotors |
| Brake Levers | Tektro HD-E395 hydraulic | Engine cut off |
| Handlebars | Railer Throwback | 805mm wide |
| Tape/Grips | Del Sol Chopper With Stitched Cover |
| Stem | Railer BMX Throwback | Alloy | ?25.4 bar bore | 1-1/8" threadless |
| Headset | 1-1/8" integrated | Threaded |
| Seatpost | 27.2mm x 250mm |
| Saddle | Del Sol Couch Plus saddle | Compression-tuned elastomers | Del Sol Hand-Holder e-bike-specific handle |
| Pedals | Boardwalk cruiser | Shock-absorbing Kraton inserts |
| Accessories & Extras | Kickstand | Integrated Rack | Rear Fender | Charger & cables |
| Battery | 48V/17.5Ah | 840Wh | Fully-integrated within down tube |
* Subject to change without notice.
Part Numbers
| Option | UPC | MPN | Store SKU |
|---|---|---|---|
| Matte Khaki / One Size | 691840316538 | 31653 | 210000016217 |
| Cherry Cola / One Size | 691840316545 | 31654 |
